C0265 Code: ABS Outlet Valve Circuit Repair Guide

⚠️ Safety Alert: Driving with C0265 disables ABS functionality. Avoid emergency braking until repaired.

🔍 Understanding Code C0265

OBD-II Code: C0265
Definition: ABS Outlet Valve Circuit Malfunction
System Impact: Anti-lock Brakes (ABS), Traction Control

This code triggers when the ABS module detects electrical faults in the outlet valve circuit, which releases brake pressure during ABS activation to prevent wheel lock-up.

Pro Tip: Many C0265 code with C0266 cases indicate hydraulic control unit (HCU) failures rather than isolated valve issues.

🚨 Symptoms

ABS and traction control warning lights on
Pulsating brake pedal during normal stops
Increased stopping distances on wet surfaces
Fluid leaks near HCU (in severe cases)

🛠️ Diagnostic Procedure

Tools Needed:

Bidirectional scan tool (e.g., iCarsoft CR Pro)
Digital multimeter
Oscilloscope (for PWM signal verification)

Step-by-Step Tests:

Resistance Check:
- Disconnect HCU and measure outlet valve resistance (spec: 3–10Ω)
- Compare with adjacent valves (e.g., inlet valve C0266)
Voltage Tests:
- Back-probe circuit during ABS activation
- Verify 12V PWM signal from ABS module
Functional Test:
- Activate valve via scan tool while monitoring brake pressure
- Listen for audible "click" from HCU

🔧 Repair Solutions

Most Common Fixes:

Wiring Repair:
- Splice damaged wires with heat-shrink tubing
- Clean corroded connectors with electrical contact cleaner
Valve/HCU Replacement:
- Some vehicles allow individual valve replacement
- Others require complete HCU assembly
