iCarsoft HD V4.0 Multi-system Heavy Duty Vehicles Diagnostic Tool

Learn More

This warranty applies only to users and distributors who purchase iCarsoft products through normal procedures. Within one year from the date of delivery, iCarsoft warrants its electronic products for damages caused by defects in materials or workmanship. Damages to the equipment or components because of abuse, unauthorized modification, use for non - designed purposes, operation in a manner not specified in the instructions, etc. are not covered by this warranty. The compensation for dashboard damage caused by the defect of this equipment is limited to repair or replacement. iCarsoft does not bear any indirect and incidental losses. iCarsoft will judge the nature of the equipment damage according to its prescribed inspection methods. No agents, employees or business representatives of iCarsoft are authorized to make any confirmation, notice or promise related to iCarsoft products.

Products tutorial, videos, Q&A and coverage list are available on iCarsoft official website.

7-10 days delivered

1、HD V4.0 5 inches heavy duty scanner with lifetime free Update
iCarsoft HD V4.0 is latest developed heavy duty diagnostic tool. It’s the enhanced version of HD V3.0. It performs a comprehensive scan of all supported systems within your commercial vehicles. In addition to the regular 4 systems such Engine, ABS, Airbag and Transmission, it covers more complex systems diagnostic functions. With 5 inches touchscreen and Wi-Fi update. The HD V4.0 is specially made for truck mechanics, DIYers, and professionals. Give your aging cars satisfying routine maintenance to avoid costly repairs, a breakdown, or even a crash.

General diagnostic functions as following:
Version Information: Read the current version information of the ECU.
Read Fault Code: Read the DTC in the ECU memory to help technicians to identify the cause of the failure.
Clear Fault Code: Delete the existing fault codes.
Read Data Stream: View and capture real-time data from ECUs.

2、Pre-installed 37 brands:
For CUMMINS, for DAF, for Mitsubishi (Diesel), for Sprinter (Diesel), for Toyota (Diesel), for USAFORD (Diesel), for Allison, for Ashok Leyland, for Bendix, for Mercedes-Benz (HD), for Bosch, for Caterpillar, for Detroit, for Doosan, for Eaton, for Eicher, for Freightliner, for Fuso, for HALDEX, for Hino, for Hyundai, for International, for Isuzu, for IVECO (Diesel), for Kenworth, for Mahindra, for MAN, for Paccar, for Peterbilt, for Renault, for Tata, for Volvo (HD), for WABCO_ABS (HD), for Western Star, for Mack, for Scania and for UD.

3、Extension software package available with additional cost.
If the pre-installed vehicle brands cannot meet the needs, the user can purchase the extension software package to get more vehicle software. Please contact us or your local agent for more details.

4、Support 8 hot service reset functions:
● DPF Regeneration
● Oil Reset
● Injector Coding
● Clutch Matching
● Brake-pad Reset
● SCR Reset
● Speed Limit Reset
●Cylinder Cut Out Test

5、HD V4.0 is a 2 in 1 OBD scanner:
The HD V4.0 code reader can scan engine module through OBD interface for both heavy duty and 12v vehicles.
a. Read and clear fault codes, turn-off malfunction indicator light (MIL).
b. O2 sensor test to check fuel efficiency and vehicle emission.
c. Display freeze frame data and retrieve vehicle information.
d. EVAP test for fuel tank system (Carbon canister test).
e. Display I/M readiness status (non-continuously monitored system test).
f. Request On-Board Monitoring test results for specific monitored systems).

6、Lifetime free online update:
In contrast to other OBDII scanner on the market that demand users to pay for updates, our HD V4.0 comes with 8 reset functions with lifetime free updates. Increasingly sophisticated software for better compatibility. And it’s one-click update after you connected with the Wi-fi.

7、Multi-language supported:
The HD V4.0 truck scanner supports English, German, Spanish, French, Italian, Japanese, Portuguese, Russian, Polish, Turkish, Dutch, Hungarian, Traditional Chinese, Korean, Greek, Slovak, Romanian, Arabic, Croatian, Slovenian, Finnish, Czech, Vietnamese, Swedish, Serbian, Farsi, Bulgarian and Danish.

8、Supplied with 3 OBDI adaptors:
OBD-6
OBD-9
CAT-9

9、Specifications:
Operating System: Android 8.1
Memory: 2GB
Storage: 64GB
CPU: MT6580 Contex-A74 1,3GHz
Screen Size: 5-inch
Battery: 3150 mAh / 3.8V
Bluetooth: BT5.0
Working Environment： -10°C ~ 50°C (14°F ~ 122°F)
Storage Environment： -20°C ~ 60°C (-4°F ~ 140°F)
Working Voltage： 5V
Working Current: ≤2.5A
Supported Protocols: SAE-J1850 PWM, SAE-J1850 VPW, ISO 9141, ISO-14230-2
ISO, ISO 14230-4 KWP, ISO 15765-4 CAN, J1708, J1939, CANFD

10、Packing list:
Carry Case
Main Unit
Main Cable
OBD-6
OBD-9
CAT-9
Charging Adaptor
User’s Manual
USB Cable
