Quick Answer
The P076A code means shift solenoid h. It does not prove a shift solenoid G fault or a confirmed stuck-off condition. Save the scan, identify the exact architecture, and test the physical and electrical paths before selecting a repair.
What Does the P076A Code Mean?
The P076A code means Shift Solenoid H. It names a monitored result, not a guaranteed failed part. The reporting module, suffix and companion faults determine the relevant test branch.
The standard base description identifies shift solenoid H. More specific circuit or performance detail must come from the reporting module and OEM procedure. Solenoid lettering does not establish a universal valve-body location, shift assignment or serviceable part. The installed transmission's apply chart and wiring diagram control the diagnosis.
The base code does not include every failure-mode detail. Preserve the full module description so a general solenoid label is not expanded into an unsupported conclusion.
Genesis bulletin 21-AT-016HG maps P076A/P076A00 to a Park/SBW solenoid or park-system branch on listed G80/G90 applications. This manufacturer wording differs from the generic H-solenoid label. Match the transmission and full fault text before applying its service instructions. P076A remains the base H-solenoid description, while P076B names performance or stuck off.
This is a source-based diagnostic guide, not a record of a vehicle tested by our team. The checks below explain how to separate evidence for shift solenoid H circuit and operation from assumptions about replacement parts.
Read the stored wording exactly as the vehicle reports it. A short generic label can hide a manufacturer suffix, a circuit-direction detail, a bank or sensor identifier, or a setup condition that changes the first test. Save that wording before clearing the record so the diagnostic path can be repeated if the fault returns.
Separate P076A from adjacent fault families
| Code | General description | Key distinction |
|---|---|---|
| P076A | Shift Solenoid H | Use the full OEM wording, status and companion faults before choosing a test path. |
| P0751 | Shift Solenoid A Performance or Stuck Off in Chevy | Related monitor family; confirm its separate fault criteria before combining repairs. |
| P0753 | Fault Code: Shift Solenoid A Electrical Issue | Related monitor family; confirm its separate fault criteria before combining repairs. |
| P0755 | Code Fix: Shift Solenoid B Malfunction Diagnosis Guide | Related monitor family; confirm its separate fault criteria before combining repairs. |
Record the complete P076A description. The suffix, reporting module and companion faults can change the diagnostic path. Use the manufacturer's full wording and test procedure for the exact vehicle.
P076A Symptoms and Likely Causes
P076A symptoms depend on fault status and the fallback strategy. Record what the driver and modules reported. A symptom list is not a parts list.
Look for patterns rather than isolated clues. A current fault with matching freeze-frame data deserves a different priority than an old history fault found during unrelated service. Companion codes can point to a shared feed, ground, connector, fluid state, mechanical path or controller condition, but they still need the same evidence-based separation.
Capture the complete wording and any failure-type suffix.
Record the affected gear transition without assuming a solenoid location.
Follow the vehicle's warning response and stop when control is unsafe.
A stored event still needs the exact module and architecture identified.
Practical cause-checking order
- Identify the monitored path: Confirm the full OEM wording and identify solenoid H in this transmission.
- Inspect accessible evidence: Inspect connector retention, harness routing and fluid-service history.
- Compare command and response: Test the applicable supply, control and load path.
- Test the suspect branch: Compare supported command with shift or hydraulic response.
- Confirm before replacement: Choose mechanical, valve-body or controller work only from the failed branch.
Did P076A appear after recent transmission, valve-body, selector, fluid or wiring work? Recheck the documented connections, parts and setup steps affected by that work. Record battery and software history; a post-repair code does not prove the new part is defective.
How Serious Is P076A, and Can You Drive?
The P076A code alone cannot establish a safe driving distance. Follow the owner’s manual and arrange diagnosis promptly. Stop if gear selection is unsafe, shifting is violent, the transmission overheats or propulsion is lost. A history record with normal operation and an active fault with a safety symptom need different responses.
Record temperature, load, speed, start state and recent service. Do not reproduce a severe symptom on public roads; another warning can make the situation more urgent. If the vehicle enters a reduced-power strategy, develops abnormal noise, leaks fluid, overheats or shows a red stop warning, the safety condition overrides any plan to complete a drive cycle.
Stop and arrange a tow if gear selection is unsafe, shifting is violent, the transmission overheats or propulsion is lost.
Secure the vehicle before selector or solenoid tests. Do not directly power an unidentified solenoid or continue a road test that produces unsafe engagement.
How to Diagnose P076A in the Right Order
-
Preserve the full solenoid record
Save P076A with its reporting module, suffix, status and companion faults. Record selector behavior, actual gear and fluid temperature where available.
-
Identify H using the OEM documentation
Match transmission code and VIN to the wiring diagram and solenoid chart. Do not turn the base label into a stuck-off diagnosis or substitute solenoid G from an incorrect lookup.
-
Inspect external evidence safely
Check connectors, terminals, harness condition and recent valve-body or fluid work. Verify applicable fluid level and specification by the proper procedure before drawing hydraulic conclusions.
-
Test the relevant electrical branch
Follow the service tree for supply, driver and load measurements. Solenoid design and control method vary, so neither a universal resistance value nor a direct battery test is appropriate.
-
Compare command with the required response
Run only supported, permitted commands. Use the specified pressure or shift-response test if the circuit passes. A scanner menu item alone cannot establish that the vehicle supports the requested function.
-
Verify the repair and setup
Repair the proven wiring, solenoid or hydraulic/control branch. Perform required configuration or adaptation and verify the relevant gear operation before checking returning codes.
Specifications are vehicle-specific. Use the exact VIN specifications, approved test points and required operating state. No generic value or drive cycle can replace the applicable procedure. Manufacturer examples here do not establish specifications for other applications.
P076A Repairs and Typical Costs
The correct P076A repair follows the failed test. Wiring, a physical repair, a proven component, software and controller work are different outcomes. Do not replace an assembly from the generic code alone.
Recheck installation and required setup after repair. Integrated solenoid assemblies may require a specific replacement variant and setup procedure; verify both before ordering.
A useful estimate should name the failed branch, not just the code. Ask whether the shop found an open, short, biased signal, missing supply, poor ground, mechanical restriction, fluid condition, calibration requirement or module fault. That wording makes the recommendation auditable and protects against replacing several unrelated parts after one stored DTC.
When the failed branch is still uncertain, pay for diagnosis before authorizing parts. A careful proof step is usually less disruptive than repeating repairs after the same monitor sets again.
| Possible path | Current US estimate |
|---|---|
| Repair a proven connector, feed or control-circuit fault | VIN-specific quote |
| Replace the correctly identified solenoid after its test fails | VIN-specific quote |
| Repair a verified valve-body or hydraulic branch | VIN-specific quote |
| Complete required configuration and shift verification | VIN-specific quote |
These are alternative repair paths, not prices to add together. Request a VIN-specific quote separating diagnosis, parts, labor, fluids, taxes, required setup and verification. Ask which failed test supports the proposed repair and whether warranty coverage applies.
Using iCarsoft CR Eagle P for P076A
On a supported vehicle, iCarsoft CR Eagle P can retrieve accessible module faults, save available freeze frame, display ECU-provided live data and create a diagnostic report. For P076A, preserve the original evidence and compare related modules before clearing an erasable record.
Use the report as a record of what the controller knew at the time. It helps compare code status, freeze-frame conditions and available PIDs before and after repair. It does not replace the wiring diagram, service procedure, safe access instructions or physical measurement required to prove the failed branch.
Preserve the shift solenoid H circuit and operation evidence
iCarsoft CR Eagle P
Review supported codes and relevant live data together. Confirm the exact VIN, controller access, PIDs and any requested active test with iCarsoft before purchase; generic product capabilities do not guarantee a P076A-specific function.
Check current CR Eagle P price and availabilityCheck CR Eagle P compatibility by VINThe official product page describes supported full-system diagnostics, available live data, freeze frame and diagnostic reports; exact controller coverage and active tests depend on the VIN and software. Confirm the requested function by VIN before purchase. Follow OEM prerequisites and stop for abnormal operation.
Know the measurement boundary. Scan data describes ECU-provided information; it does not directly prove the physical condition of the shift solenoid H circuit and operation. Use a meter, appropriate current-testing tools and the specified transmission response or pressure equipment where required, and compare reported values with the relevant measured evidence.
Verify the P076A Repair
After repair, verify connectors, harness clearance, setup and controller supply. Save post-repair findings, then clear only erasable records through the approved procedure. Battery disconnection is not a repair.
Run the manufacturer's applicable verification conditions in a safe workshop or route. Compare the original operating state with current data for the shift solenoid H circuit and operation, and check current and pending faults in related modules. One clean start or idle period does not prove that every conditional monitor has completed.
Document what changed between the first scan and the verification scan. Useful notes include module status, current versus history state, freeze-frame differences, whether the same enabling conditions returned, and whether a relearn or service function was accepted. Preserve the original diagnostic fault order. This record helps separate an incomplete monitor from a repair that failed under the same conditions.
If P076A returns, compare its suffix, status, failure order and operating conditions with the saved baseline before replacing another part. Revisit the failed branch and inspect anything disturbed. Keep mechanical repair, monitor completion, readiness and local inspection eligibility as separate outcomes.
A permanent P076A can remain immediately after a successful repair. If stored as a permanent DTC, it cannot be erased by a scan tool or battery disconnect. The vehicle must complete the applicable successful monitor verification.
Related Shift Solenoid H Circuit And Operation Code Guides
Use related-code pages to compare monitor families, not to merge repairs. A nearby code can share a component, circuit, fluid path or operating condition, but its diagnostic conclusion still depends on its own status, suffix and test evidence.
P076A Frequently Asked Questions
Does the P076A code mean the named component is bad?
No. P076A describes shift solenoid h, not a confirmed part. It also does not prove a shift solenoid G fault or a confirmed stuck-off condition. Use the OEM test sequence to distinguish the circuit, load and controller before replacing parts.
What should I check first for P076A?
Save every module's codes and freeze frame before clearing. Confirm the full definition, suffix and VIN architecture. Then inspect recent transmission, valve-body, selector, fluid or wiring work, connectors and shared supplies. Those facts determine whether the next test needs a meter, appropriate current-testing tools and the specified transmission response or pressure equipment or a manufacturer-specific functional procedure.
Can I drive with the P076A code?
The P076A code alone cannot establish a safe driving distance. Follow the owner’s manual and arrange diagnosis promptly. Stop if gear selection is unsafe, shifting is violent, the transmission overheats or propulsion is lost. A history record with normal operation and an active fault with a safety symptom need different responses.
Why did P076A return after a part was replaced?
The wrong solenoid, an unresolved shared circuit or missing setup can leave the original fault after a component was replaced.
What should a P076A repair estimate include?
Ask for the failed-test evidence and a VIN-specific breakdown of diagnosis, parts, labor, taxes, required setup and verification. A code alone cannot establish the repair price.
Can CR Eagle P diagnose and clear P076A?
On a supported vehicle, CR Eagle P can organize available faults, freeze frame, live data and reports, and can clear erasable records after repair. Confirm exact ECU coverage. It cannot force-clear a permanent DTC or replace physical measurements for the shift solenoid H circuit and operation.
The iCarsoft Official Store Technical Team maintains the store's fault-code library. This guide organizes published manufacturer evidence and verified product information; it does not document a hands-on test of a particular vehicle or claim an individual engineer's review.
