Quick Answer
The P00B4 code means Radiator Coolant Temperature Sensor Circuit High. The engine controller detected a high electrical state in the OEM-defined radiator coolant temperature sensor circuit. GM's published monitor describes a short to high or an open in the RCT signal circuit or sensor. P00B4 does not by itself prove that the coolant is hot or that the sensor must be replaced.
What Does the P00B4 Code Mean?
P00B4 is a generic powertrain DTC for a high electrical condition in the radiator coolant temperature, or RCT, sensor circuit. On a documented GM application, the controller interprets that condition as a short toward a high source or an open in the RCT signal path or sensor.
High describes the circuit state, not hot coolant. An open temperature-sensor connector can produce an extremely cold or high-state scan value. Voltage, resistance, pin assignment, and thresholds are vehicle-specific.
| Code | Standard description | Key distinction |
|---|---|---|
| P00B1 | Radiator Coolant Temperature Sensor Circuit | General circuit classification. |
| P00B2 | RCT Sensor Circuit Range/Performance | Plausibility or response, not a dedicated high code. |
| P00B3 | RCT Sensor Circuit Low | Low-state electrical direction. |
| P00B4 | RCT Sensor Circuit High | High-state or open-circuit direction. |
| P00B5 | RCT Sensor Circuit Intermittent/Erratic | Signal changes too quickly or drops out. |
| P00B6 | RCT/Engine Coolant Temperature Correlation | The two temperature signals disagree after defined conditions. |
RCT is not automatically ECT. The sensors may occupy different coolant locations. Use the VIN, engine code, diagram, and component locator before testing or ordering a part.
P00B4 Symptoms and Likely Causes
P00B4 may cause only a Check Engine Light; other symptoms depend on the vehicle's fallback strategy.
The MIL may be steady, with P00B4 current, pending, history, or permanent.
Some controllers run the fan continuously or use a conservative default when the signal is invalid.
RCT may appear fixed, extremely cold, or inconsistent with ambient, ECT, and warm-up behavior.
Some vehicles may limit A/C, remote start, temperature management, or engine performance.
Evidence-led cause order
- An unplugged, loose, corroded, contaminated, or poorly seated RCT connector.
- An open signal or low-reference circuit from a broken wire, spread terminal, chafing, heat, or recent work.
- A signal wire shorted to voltage or another powered circuit.
- An internally open or out-of-spec RCT sensor.
- A shared reference, ground, connector, or controller-input fault when several sensor codes coexist.
- PCM or ECM hardware or calibration only after every external path passes.
Do not start with coolant or a thermostat. Low coolant, a leak, trapped air, or a thermostat fault can coexist and must be corrected, but P00B4 is an electrical circuit-high classification. Prove why the signal is high before replacing cooling-system parts.
How Serious Is P00B4, and Can You Drive?
Treat P00B4 as a moderate, service-soon fault. A short, gentle diagnostic trip may be reasonable if the MIL is steady, actual coolant level and temperature are normal, and there is no leak or steam. Avoid towing, hard acceleration, and long drives.
Stop and tow for a temperature warning, steam, coolant loss, severe power loss, a flashing MIL, severe misfire, or abnormal noise. Never open a hot radiator or expansion tank.
Electric fans can start unexpectedly. Keep hands, leads, clothing, and tools clear of fans, belts, and pulleys.
How to Diagnose P00B4 in the Right Order
-
Save every pre-repair clue
Scan all modules before clearing anything. Record P00B4 status, exact wording, freeze frame, failure order, battery voltage, RCT and ECT data, and companion fan, thermostat, reference-voltage, or temperature-sensor codes.
-
Identify the exact RCT architecture
Use the VIN and engine code to obtain the diagram, location, connector view, monitor criteria, bulletins, and limits. Confirm you are not testing the ECT sensor.
-
Inspect the cold system
With the engine cool, inspect coolant level and leaks, the sensor body and seal, connector lock, terminal condition, harness clips, rub points, heat damage, water intrusion, and signs of recent radiator or front-end work.
-
Prove the circuit physically
Follow the OEM tree with the specified meter, load, terminal tools, or breakout leads. Test supply, low reference, continuity, shorts to voltage, terminal tension, and voltage drop.
-
Compare supported temperature data
After an adequate cold soak, compare RCT with ECT and intake-air or ambient temperature, then graph warm-up behavior. Use a supported cooling-fan active test only when safe; scan data and a command result do not replace circuit proof.
-
Confirm the failed layer and repair
Distinguish the connector, wiring, serviceable sensor, shared circuit, and controller. Replace or repair only the proven layer, refill and bleed the specified coolant if the system was opened, perform required setup, and consider the controller last.
No universal meter value applies. A resistance or voltage copied from another model can condemn a good sensor or damage a module. Back-probe only when approved, never substitute a jumper across unknown circuits, and use the vehicle's temperature-to-resistance or voltage table.
P00B4 Repairs and Typical Costs
Repair the proven connector, wire, terminal, sensor, shared circuit, software, or—rarely—controller fault. Clear P00B4 only after correction.
| Possible path | Current US planning estimate |
|---|---|
| Electrical-system diagnosis used as a general circuit-testing anchor | $122–$179 |
| Engine coolant temperature sensor replacement used only as an adjacent national planning anchor; an RCT sensor may differ | $489–$573 |
| Connector, terminal, harness, radiator-specific sensor, coolant refill, or bleed | VIN-specific quote |
| Software, controller diagnosis, programming, or module replacement | VIN-specific quote |
RepairPal last updated both cited estimators on August 7, 2026. Its national ranges exclude taxes, fees, location, and related repairs. The ECT replacement range is context, not a quote for every radiator sensor: location, serviceability, coolant requirements, parts, and labor can differ substantially.
Using iCarsoft CR Max P for P00B4
On a supported vehicle, iCarsoft CR Max P can read the reporting module, save P00B4 and available freeze frame, graph exposed RCT, ECT, intake-air, fan-command, and voltage data, and create a pre- and post-repair report. Supported cooling-fan tests or setup functions vary by VIN, ECU, software, and gateway.
Supported-vehicle cooling-system diagnostics
iCarsoft CR Max P
Preserve the scan evidence, compare available temperature PIDs, and run supported fan tests while proving the circuit with the correct external instruments.
Check current CR Max P price and availabilityCheck CR Max P compatibility by VINA scan tool cannot directly measure terminal grip, circuit resistance, a short to voltage, coolant condition, system pressure, or actual temperature.
Use the right tool for each layer. Combine CR Max P scan evidence with the OEM wiring diagram, a meter and approved test leads, physical inspection, and—when necessary—a thermometer, pressure tester, or cooling-system service equipment.
Verify the P00B4 Repair
Save a post-repair scan and confirm that connectors are locked, the harness is supported, coolant is correct when cold, no leak remains, and any required bleed or setup is complete. Clear erasable DTCs with the approved method, then reproduce the original enable conditions.
Compare RCT with relevant cold-soak temperatures, watch for a smooth and plausible warm-up trend, verify normal fan strategy, and rescan after the road test. P00B4 should be absent as a current and pending code, and no new shared-circuit or cooling fault should appear.
A permanent P00B4 may remain briefly after a successful repair. A scan tool or battery disconnect cannot directly erase a permanent DTC. Once current and pending faults are gone, the OBD system removes it after the applicable monitor runs and passes.
Related Coolant-Temperature Code Guides
P00B4 Frequently Asked Questions
Does P00B4 mean the engine is overheating?
No. “Circuit high” describes an electrical state, and an open connector can create it. Check actual coolant condition and temperature separately, and stop immediately for steam, coolant loss, or an overheat warning.
What usually causes the P00B4 code?
Common paths are an unplugged or corroded connector, an open signal or low-reference wire, a short to voltage, or an internally open RCT sensor. A controller fault is possible but uncommon and should be considered last.
Are the radiator coolant and engine coolant temperature sensors the same?
Not necessarily. P00B4 names the OEM-defined radiator coolant temperature circuit. Some vehicles have a separate RCT sensor and ECT sensor in different coolant locations, so identify both from VIN-specific service information.
Can I drive with a P00B4 code?
A short, gentle diagnostic trip may be reasonable when the MIL is steady, actual temperature and coolant are normal, and there is no leak, steam, misfire, severe power loss, or noise. Stop and tow for any overheating evidence.
How much does P00B4 cost to repair?
A current national electrical-diagnosis anchor is $122–$179. RepairPal lists $489–$573 for engine coolant temperature sensor replacement, but an RCT sensor may be different; wiring, sensor access, coolant service, and programming require a VIN-specific quote.
Can iCarsoft CR Max P diagnose P00B4?
On supported vehicles, it can preserve codes and freeze frame, graph exposed RCT and comparison data, and run available fan tests. A meter, physical inspection, and the OEM circuit procedure are still needed to prove an open, short, terminal, or sensor fault.
Technical and cost references
- GM 14OBDG02 Engine Diagnostics — P00B3, P00B4, P00B6 definitions and application-specific monitor descriptions.
- BMW official SAE P-Code List — standardized radiator coolant temperature code-family descriptors.
- RepairPal Electrical System Diagnosis Cost Estimate — $122–$179, updated August 7, 2026.
- RepairPal Engine Coolant Temperature Sensor Replacement Cost Estimate — $489–$573, updated August 7, 2026; adjacent planning context, not an RCT-specific quote.
Product information: Official iCarsoft CR Max P page.
Editorial note: This guide provides general educational information, not a substitute for the service manual, wiring diagram, hot-coolant precautions, and test limits for a specific VIN. Prices are US planning estimates and can change. Confirm repair procedures, product coverage, and local pricing before work begins.
