Quick Answer
P0765 identifies a malfunction in the OEM-defined Shift Solenoid D control path. It does not prove that the solenoid itself is bad or identify a universal gear, location, pin, or resistance. Save the complete fault record, identify the transmission by VIN, and test power, ground, connectors, external and internal wiring, and the solenoid load before authorizing internal work.
What Does the P0765 Code Mean?
The standardized base label for the P0765 code is Shift Solenoid “D.” Many scanners add “malfunction” or “circuit” to make the result easier to understand. The safe interpretation is that the transmission controller detected an unacceptable result in the manufacturer-defined Solenoid D path. The five-character code alone does not identify the failed part.
Shift solenoids let the transmission controller direct hydraulic pressure to different valves, clutches, or brakes. The exact job assigned to Solenoid D changes with transmission design. It may be a separate serviceable valve, part of a solenoid pack, attached to an internal harness, or built into a valve body or mechatronic assembly. Use the VIN and transmission identification before locating or testing it.
OEM logic can also differ. In the 2006 Nissan Maxima service manual, P0765 can set when normal voltage is not applied because of an open or short, or when target and monitored values disagree. A 2023 Stellantis bulletin lists the same five-character code as “Shift Solenoid D” on one transmission and “UD Solenoid Circuit” on another. These examples show why the complete OEM descriptor and failure subtype matter.
P0765 compared with adjacent Shift Solenoid D codes
| Code | General description | Key distinction |
|---|---|---|
| P0765 | Shift Solenoid D / malfunction | Base control-path fault; preserve the OEM wording and subtype. |
| P0766 | Shift Solenoid D performance or stuck off | Commanded operation did not produce the expected functional response. |
| P0767 | Shift Solenoid D stuck on | The hydraulic or shift response indicates unwanted continued application. |
| P0768 | Shift Solenoid D electrical | Explicit electrical classification; test the exact circuit and load. |
| P0769 | Shift Solenoid D intermittent | The electrical result is not continuously repeatable. |
The letter D is a functional label. It does not universally mean the fourth solenoid, fourth gear, overdrive, or a specific valve-body position. Manufacturer names such as “UD” or application-specific shift assignments must come from the exact service information.
P0765 Symptoms and Likely Causes
A current P0765 code may appear with obvious shifting trouble, but an intermittent or history fault can begin with only a warning light. Symptoms depend on which clutch or pressure path the transmission assigns to Solenoid D and on the protective strategy chosen by the controller.
The check-engine or transmission lamp may illuminate before the driver notices a shift problem.
The controller may increase line pressure, inhibit a shift, or hold a default gear.
Input speed can rise without the expected output-speed change when a clutch does not apply correctly.
Some applications may lose a needed range, default to failsafe, or refuse normal operation.
Practical cause-checking order
- Recent work or connector disturbance: a loose case connector, damaged seal, backed-out terminal, pin fit problem, trapped harness, or wrong part after valve-body or transmission work.
- Power, ground, and shared control paths: low system voltage, a failed protected feed, poor TCM ground, fuse or relay trouble, or a common path affecting several solenoids.
- External wiring: an open, short, excessive resistance, heat damage, abrasion near mounts, corrosion, water entry, or fluid migration.
- Internal wiring or the Solenoid D load: a damaged conductor plate, lead frame, internal harness, connector, or heat-sensitive/open solenoid coil.
- Hydraulic or mechanical response: incorrect fluid level, a restricted valve, debris, worn valve body, clutch damage, or pressure loss when performance evidence supports this layer.
- Controller, software, or configuration: consider a driver fault, calibration issue, or mismatched assembly only after the external circuit and commanded load pass.
Do not apply battery power directly to an unknown solenoid circuit. Modern transmissions can use pulse-width modulation, current regulation, low-resistance loads, or an integrated controller. A jumper or incandescent test light can damage the solenoid or TCM.
How Serious Is P0765, and Can You Drive?
Treat a current P0765 code as a prompt diagnosis issue. If the vehicle engages normally, has no slip, leak, overheating, abnormal noise, or harsh impact, a short light-load trip to a safe inspection location may be reasonable when the owner’s manual permits it. There is no universal safe mileage, and repeated road testing can turn an electrical fault into heat and clutch damage.
Stop and arrange a tow if the transmission slips, bangs into gear, loses Drive or Reverse, cannot hold a needed range, remains in failsafe, overheats, leaks heavily, smells burnt, or makes new scraping, knocking, or contact noise. Also stop for a flashing MIL, severe engine misfire, smoke, or another critical warning.
Transmission fluid and exhaust components can be hot, and a commanded solenoid test may apply a clutch or rotate raised wheels. Follow the OEM restraint, lift, temperature, and pressure-test procedures. Never work under a vehicle supported only by a jack or remove a pressurized plug without the prescribed precautions.
How to Diagnose P0765 in the Right Order
-
Save the complete fault record
Before clearing anything, scan every module and record P0765 code status, the full OEM description and failure subtype, freeze frame, battery voltage, failure order, and companion transmission, power-supply, network, speed-sensor, pressure, ratio, or temperature codes. Several solenoid codes together point toward a shared feed, connector, ground, internal harness, or module supply.
-
Identify the exact transmission and Solenoid D path
Use the VIN, transmission tag, calibration, and current service information. Confirm the OEM solenoid name, connector views, pins, control method, clutch assignment, and whether the part is separate, packaged, or integrated. Check applicable bulletins and recent repair history before ordering a component.
-
Inspect connectors, routing, and the physical system
With the vehicle cool and safely supported, inspect the TCM and transmission case connectors, locks, seals, terminal tension, corrosion, water or ATF intrusion, and harness routing near heat, brackets, mounts, and moving parts. Check fluid condition and level only by the exact OEM temperature and procedure.
-
Prove power, ground, circuit integrity, and load
Protect modules as directed, then use the specified DVOM, current probe, oscilloscope, breakout lead, or approved load. Test feeds and grounds under load, voltage drop, opens, shorts, and the internal path in the required sequence. Compare coil resistance only with the VIN-specific value and specified fluid or component temperature.
-
Compare supported command and response data
Review available Solenoid D command, driver status, current or duty cycle, gear, input and output speed, ratio, fluid temperature, pressure-switch, and clutch-state data. If an approved active test exists, meet every prerequisite and stop for movement, harsh engagement, heat, or noise. Scan data supports the diagnosis; it does not physically prove wiring or hydraulic pressure.
-
Confirm the failed layer and required setup
If the external path passes, isolate the case connector, internal harness, conductor plate, coil, valve-body response, and controller driver in the OEM order. Condemn a module or major assembly last. Before repair approval, confirm part serviceability, correct fluid, programming, solenoid characterization, initialization, or adaptive-learning requirements and the post-repair monitor.
Specifications are vehicle-specific. Do not transfer voltage, resistance, current, pressure, temperature, gear, time, or drive-cycle values from another transmission. Even an OEM example for P0765 applies only to the identified design and conditions.
P0765 Repairs and Typical Costs
The right repair is the smallest proven correction. That may be terminal or harness repair, restoration of a shared power or ground, replacement of a serviceable internal lead or Solenoid D, an integrated solenoid body or valve body, or a narrowly supported software/configuration action. Fluid service is appropriate only when condition, level, contamination, or an OEM procedure justifies it; it cannot repair an open circuit.
| Possible path | Current US estimate |
|---|---|
| Professional check-engine diagnosis and testing | $122–$233 |
| Connector, terminal, external harness, feed, or ground repair | VIN-specific quote |
| Internal harness, conductor plate, serviceable Solenoid D, or solenoid pack | VIN-specific quote |
| Valve body or mechatronic assembly with required fluid and setup | VIN-specific quote |
| TCM repair, programming, or transmission internal work after proof | VIN-specific quote |
RepairPal’s Check Engine Light Diagnosis & Testing estimate was last updated August 7, 2026 and lists $122–$233 before taxes, fees, location differences, or related repairs. It is a diagnostic anchor, not a Solenoid D replacement price. All repair rows are alternatives, not amounts to add together; design, access, fluid, seals, programming, local labor, and collateral damage can change the quote.
Using iCarsoft CR Max P for P0765
On a supported vehicle, iCarsoft CR Max P can access the transmission controller, preserve P0765 status and available freeze frame, run a full-system scan, display ECU-provided live data, and save a diagnostic report. Useful command, driver, current, gear, speed, ratio, pressure-switch, clutch-state, or active-test data may be available when the exact VIN, ECU, and software expose it.
Evidence-led transmission diagnosis
iCarsoft CR Max P
Preserve the complete fault record, graph supported transmission data, and compare available commands with ECU-reported response before replacing parts. Coverage and active tests are vehicle-specific.
Check current CR Max P price and availabilityCheck CR Max P compatibility by VINWhen the transmission offers an approved bidirectional test, CR Max P may help compare the requested state with scan feedback. Confirm prerequisites and secure the vehicle because an output command can apply a clutch. A missing PID or a test that is not offered means the coverage is not exposed for that application; it is not evidence that a vehicle part failed.
Know the measurement boundary. CR Max P does not directly measure voltage drop, current waveform, coil resistance, terminal tension, hydraulic pressure, leakage, valve travel, or internal clutch condition. Use the required DVOM, scope, current probe, pressure equipment, physical inspection, and OEM procedure alongside scan evidence.
Verify the P0765 Repair
Save the post-repair scan and physical test results. Confirm correct connector locks and seals, harness clearance, no fluid intrusion or terminal heating, correct fluid level by the prescribed temperature method, and completion of any required programming, characterization, initialization, or adaptive learning.
After the original evidence is preserved, clear erasable DTCs with the OEM procedure. Run the actual confirmation conditions or safely reproduce relevant freeze-frame conditions; do not substitute one clean idle period for a monitor that requires shifting, temperature, load, or speed criteria. Compare supported command and response data, engagement quality, shift behavior, and input/output speed relationships.
Finish with a full rescan. P0765 should not be current or pending, and no new electrical, pressure, ratio, speed, temperature, or network code should appear. If the code returns immediately, recheck the control path and part/configuration match. If it returns only under heat, vibration, or a particular shift, use that repeatable condition to isolate an intermittent electrical or hydraulic layer safely.
A permanent P0765 can remain immediately after a successful repair. If the vehicle stores it as a permanent DTC, a scan tool or battery disconnect cannot erase it. Once current and pending faults are absent, the OBD system removes the permanent record only after the applicable monitor reruns and passes.
Related Transmission Code Guides
P0765 Frequently Asked Questions
Does P0765 mean Shift Solenoid D is bad?
No. P0765 identifies the OEM-defined Solenoid D control path, not a confirmed failed valve. Wiring, terminals, shared power or ground, an internal harness, the coil, valve body response, software, or the controller can produce the monitored result.
What is the difference between P0765 and P0768?
P0765 is the base Shift Solenoid D code, while P0768 is the explicit generic electrical descriptor. OEM failure subtypes can narrow P0765 further, so preserve the full scan wording and follow the exact transmission test plan.
Where is Shift Solenoid D located?
There is no universal location. “D” is a functional designation, not a fixed physical order. The solenoid may be separate, inside a pack, attached to an internal harness, or integrated into a valve body or mechatronic assembly.
Can low or dirty transmission fluid cause P0765?
Fluid level or condition can affect hydraulic response and may accompany performance, pressure, ratio, or slip evidence. It does not repair an open wire, poor terminal, failed coil, or controller driver. Check fluid only with the OEM method.
How much does it cost to diagnose P0765?
RepairPal lists $122–$233 for check-engine diagnosis and testing, updated August 7, 2026, before taxes, fees, location, and related repairs. Actual P0765 repair cost requires the VIN, transmission design, proof of the failed layer, and a local quote.
Can CR Max P diagnose the P0765 code?
On a supported vehicle, CR Max P can read the transmission module, save codes and freeze frame, display exposed live data, and run supported output tests or relearns. Physical electrical and hydraulic proof still requires external instruments and OEM service information.
Technical and cost references
- SAE J2012_202509, Diagnostic Trouble Code Definitions, revised September 2025, and SAE J2012DA Digital Annex, revised July 2026.
- 2006 Nissan Maxima Automatic Transaxle service manual, AT.fm, Revision October 2006, DTC P0765 Shift Solenoid Valve D pages AT-172 through AT-176; used only as an application-specific monitor and circuit-test example.
- Stellantis Technical Service Bulletin 18-024-23 REV. A, July 29, 2023; a narrow software-update example listing P0765 for DG7 and UD-solenoid applications.
- RepairPal Check Engine Light Diagnosis & Testing Cost Estimate, $122–$233, last updated August 7, 2026.
- iCarsoft US compatibility-by-VIN support for exact module access, PIDs, output tests, and required service functions.
Product information: Official iCarsoft CR Max P page.
Editorial note: This article provides general educational guidance, not a substitute for the wiring diagrams, test limits, lifting instructions, hot-fluid precautions, and service procedures for a specific VIN. A transmission can engage unexpectedly during output or hydraulic testing. Costs are US planning context and can change. Confirm product coverage, repair procedure, and local pricing before work begins.
