The P0216 trouble code indicates an injection timing control circuit malfunction, primarily in diesel engines, affecting fuel injection timing and performance in vehicles like the P0216 Dodge Ram and P0216 Volkswagen. This guide covers causes, symptoms, and fixes, using the iCarsoft CR MAX for diagnostics.

1. What Does P0216 Mean?

P0216 is an OBD-II diagnostic trouble code (DTC) defined as "Injection Timing Control Circuit Malfunction." The Engine Control Module (ECM) detects a fault in the fuel injection timing control circuit, often in diesel engines, where the high-pressure injection pump timing fails to meet specifications. This disrupts fuel delivery, leading to inefficient combustion. Related codes include P0118, P0119, P0120, P0128, P0130, and P0173.

Role of Injection Timing

In diesel engines, precise fuel injection timing ensures optimal combustion, power, and emissions. A P0216 injection timing control circuit malfunction causes the ECM to detect timing errors, potentially cutting injector operation during certain conditions like deceleration.

2. Causes of P0216 Injection Timing Control Circuit Malfunction

Common causes of P0216 injection timing control circuit malfunctions include:

• Faulty Fuel Injection Pump: Malfunctioning high-pressure pump disrupts timing. Example: In a 2005 Dodge Ram 2500 5.9L Cummins, pump failure triggered P0216.
• Wiring/Connector Issues: Damaged harness, corrosion, or loose connections in the timing circuit.
• Crankshaft/Camshaft Position Sensor Failure: Sensors provide timing data; faults cause ECM errors.
• Fuel System Problems: Low pressure, aerated fuel, or clogged filters affect injection.
• ECM Software Fault: Rare; outdated or corrupted ECM software misinterprets signals.

3. Symptoms of P0216

Symptoms of a P0216 injection timing control circuit malfunction include:

• Check Engine Light: Illuminates due to ECM detection.
• Limited Speed: Vehicle may not exceed 30 mph (limp mode).
• Engine Surging/Stalling: Unstable RPM, surging, or sudden shutdown.
• Poor Acceleration: Reduced power and hesitation.
• Low Fuel Pressure: Indicates pump or filter issues.

Learn more about OBD-II codes at Car and Driver.

4. Vehicles Prone to P0216

P0216 is common in diesel vehicles, especially those with high-pressure common rail systems, including:

• P0216 Dodge Ram fix (2002-2010 5.9L Cummins): Faulty fuel injection pump, surging.
• P0216 Volkswagen repair (TDI models 2004-2015): Wiring issues, limp mode.
• Ford F-250 Super Duty (2011-2016 Power Stroke): Sensor failures, stalling.
• Chevrolet Silverado (2001-2007 Duramax): Fuel system restrictions, poor acceleration.
• GMC Sierra (2004-2013 Duramax): ECM software faults, check engine light.

5. Severity of P0216

P0216 is highly severe in diesel engines, potentially causing engine damage from improper fuel injection. It triggers limp mode, reduces power, and risks further fuel system failure if ignored.

6. Can I Drive with P0216?

Driving with P0216 is not recommended, as it activates limp mode (limited to ~30 mph), causes surging/stalling, and may lead to engine damage. Stop and diagnose immediately using the iCarsoft CR MAX .

7. How to Diagnose P0216

Diagnose P0216 injection timing control circuit malfunctions using the iCarsoft CR MAX :

1. Connect Scanner: Plug into OBD-II port; read P0216 and freeze-frame data.
2. Visual Inspection: Check wiring, connectors, and fuel pump for damage.
3. Fuel Pressure Test: Verify 10-18 psi; check for aeration or restrictions.
4. Sensor Check: Test crankshaft/camshaft sensors with multimeter.
5. ECM Scan: Monitor injection timing signals via live data.

8. How to Fix P0216

Fixes for P0216 injection timing control circuit malfunctions include:

• Replace Fuel Injection Pump: For high-pressure failures (~$500-$1500). Example: Dodge Ram pump replacement resolves surging.
• Repair Wiring/Connectors: Fix damaged harness (~$100-$300).
• Replace Sensors: Crankshaft/camshaft position sensors (~$50-$200 each).
• Service Fuel System: Replace filter, bleed air, or fix lift pump (~$100-$400).
• ECM Reprogram: Update software if faulty (~$100-$200).

9. Cost to Repair P0216

Repair costs for P0216 injection timing control circuit malfunctions vary:

• Fuel Injection Pump: $500-$1500 (parts) + $200-$500 (labor) = $700-$2000.
• Wiring/Sensor Repair: $100-$400.
• Fuel System Service: $100-$500.
• ECM Update: $100-$200.
• Total Average: $300-$1500; higher for pump replacement.

10. How to Clear P0216

Clear P0216 after repairs:

1. Use Scan Tool: Connect iCarsoft CR MAX ; select "Clear Codes."
2. Battery Disconnect: Disconnect negative terminal for 10-15 minutes (resets ECM).
3. Test Drive: Verify code doesn't return; monitor fuel pressure and timing.

11. Preventing P0216 Issues

• Regular Fuel System Maintenance: Change fuel filter every 15,000-30,000 miles.
• Inspect Wiring/Sensors: Check during diesel service intervals.
• Use Quality Fuel: Avoid contaminated diesel to prevent pump wear.
• Routine Diagnostics: Use iCarsoft CR MAX for scans.

12. Benefits of iCarsoft CR MAX for P0216

The iCarsoft CR MAX excels in diagnosing P0216 injection timing control circuit malfunctions:

• Live Data: Monitors fuel pressure (10-18 psi) and injection timing.
• Bi-Directional Tests: Actuates pump and sensors for testing.
• Code Clearing: Resets ECM after repairs.
• Diesel Compatibility: Supports Cummins, Duramax, and VW TDI engines.

13. User Case Studies

14. FAQs About P0216

Q: What causes a P0216 injection timing control circuit malfunction?
A: Faulty fuel injection pump, wiring issues, sensor failures, fuel system restrictions, or ECM errors.

Q: Is it safe to drive with P0216?
A: No, it triggers limp mode and risks engine damage. Diagnose with iCarsoft CR MAX .

Q: How does P0216 differ from P0130 or P0173?
A: P0216 is diesel injection timing; P0130 is O2 sensor circuit, P0173 is fuel trim Bank 2.

Q: Can P0216 cause engine damage?
A: Yes, improper timing may harm injectors or pistons.

Q: How long does it take to fix P0216?
A: 2-4 hours for pump replacement; 1 hour for wiring.

Q: Can I fix P0216 myself?
A: Yes, with tools like iCarsoft CR MAX for diagnosis.

Q: How much does P0216 repair cost?
A: $300-$2000, mainly for pump replacement.

Q: How often should I service diesel fuel systems?
A: Every 15,000-30,000 miles for filters and checks.

15. Summary

The P0216 injection timing control circuit malfunction affects diesel vehicles like the P0216 Dodge Ram and P0216 Volkswagen, causing limp mode and surging. Use the iCarsoft CR MAX to diagnose and fix pump or wiring issues, preventing engine damage.
